WQS submersible sewage pumps

The WQ、WQAS、WQJY sewage submersible pump is widely used for discharge sewage and sludge from all kinds of harsh environment. It can not only replace clean water pump to convey clean water, but also transport sewage, feces, canal mud or mixture liquid contains sediment, fiber and other insoluble solids.

The pump can pump dry surface waters with its downdraft structure, its characteristics of remarkable energy saving, anti-winding, no clogging made it became an advanced energy-saving product at home and abroad. It completely dive to medium to work without any other device, and its installation, use and maintenance are convenient. This electric pump is the best sewerage because of its environment pollution-free in use and low noise.

Flow：10m3/h—2600m3/h Head：7m—80m

Motor power：3kW—110kW Rated voltage：380V

Two, technical parameters

型號	客流量(m3/h)	揚程	同時進行革命 (r/min)	聚氯乙烯 (V)	發電機權力(kW)	借助細顆粒物更加最大有關直徑	流出標準
WQS10-21-3	10	21	3000	380	3	25	50
WQS15-20-3	15	20	3000	380	3	25	50
WQS25-15-3	25	15	3000	380	3	25	50
WQS40-12-3	40	12	3000	380	3	25	50
WQS30-40-15	30	40	1500	380	15	30	100
WQS45-32-15	45	32	1500	380	15	30	100
WQS50-31-15	50	31	1500	380	15	30	100
WQS60-34-15	60	34	1500	380	15	30	100
WQS80-30-15	80	30	1500	380	15	30	100
WQS100-22-15	100	22	1500	380	15	30	100
WQS50-13-5.5	50	13	1500	380	5.5	30	100
WQS70-10-5.5	70	10	1500	380	5.5	30	100
WQS80-11-5.5	80	11	1500	380	5.5	30	100
WQS90-10-5.5	90	10	1500	380	5.5	30	100
WQS120-15-15	120	15	1500	380	15	45	150
WQS140-16-15	140	16	1500	380	15	45	150
WQS160-15-15	160	15	1500	380	15	45	150
WQS180-11-15	180	11	1500	380	15	45	150
WQS180-15-15	180	15	1500	380	15	45	150
WQS200-10-15	200	10	1500	380	15	45	150
WQS200-14-15	200	14	1500	380	15	45	150
WQS230-14-15	230	14	1500	380	15	45	150
WQS240-9-15	240	9	1500	380	15	45	150
WQS240-13-15	240	13	1500	380	15	45	150
WQS300-10-22	300	10	1500	380	22	45	150
WQS600-7-22	600	7	1500	380	22	45	300
WQS1100-10-55	1100	10	1500	380	55	45	300
